Intel Core i7 Extreme Edition - Page 67

Land Listing
Datasheet 67
G1 DDR0_DQ[44] CMOS I/O
G10 DDR2_DQ[37] CMOS I/O
G11 DDR2_DQ[36] CMOS I/O
G12 VSS GND
G13 DDR1_WE# CMOS O
G14 DDR1_RAS# CMOS O
G15 DDR0_CS#[0] CMOS O
G16 DDR2_CS#[0] CMOS O
G17 VDDQ PWR
G18 DDR2_MA[2] CMOS O
G19 DDR1_CLK_P[1] CLOCK O
G2 VSS GND
G20 DDR1_CLK_N[1] CLOCK O
G21 DDR2_CLK_N[2] CLOCK O
G22 VDDQ PWR
G23 DDR2_MA[12] CMOS O
G24 DDR1_MA[9] CMOS O
G25 DDR2_MA[15] CMOS O
G26 DDR2_CKE[1] CMOS O
G27 VDDQ PWR
G28 RSVD
G29 RSVD
G3 DDR0_DQ[35] CMOS I/O
G30 RSVD
G31 RSVD
G32 VSS GND
G33 RSVD
G34 RSVD
G35 RSVD
G36 RSVD
G37 VSS GND
G38 RSVD
G39 DDR2_DQ[29] CMOS I/O
G4 DDR1_DQ[42] CMOS I/O
G40 DDR2_DQ[24] CMOS I/O
G41 DDR0_DQS_N[2] CMOS I/O
G42 VSS GND
G43 RSVD
G5 DDR1_DQ[46] CMOS I/O
Table 4-2. Land Listing by Land Number
(Sheet 25 of 36)
Land
No.
Pin Name
Buffer
Type
Direction
G6 DDR1_DQS_N[5] CMOS I/O
G7 VSS GND
G8 DDR1_DQ[37] CMOS I/O
G9 DDR1_DQ[44] CMOS I/O
H1 DDR0_DQ[41] CMOS I/O
H10 VSS GND
H11 RSVD
H12 DDR2_DQ[38] CMOS I/O
H13 DDR2_DQ[34] CMOS I/O
H14 DDR1_MA[10] CMOS O
H15 VDDQ PWR
H16 RSVD
H17 DDR2_MA[10] CMOS O
H18 DDR1_CLK_P[3] CLOCK O
H19 DDR1_CLK_N[3] CLOCK O
H2 DDR0_DQ[40] CMOS I/O
H20 VDDQ PWR
H21 DDR2_CLK_P[2] CLOCK O
H22 DDR2_MA[9] CMOS O
H23 DDR2_MA[11] CMOS O
H24 DDR2_MA[14] CMOS O
H25 VDDQ PWR
H26 DDR1_MA[14] CMOS O
H27 DDR1_BA[2] CMOS O
H28 DDR1_CKE[0] CMOS O
H29 RSVD
H3 DDR0_DQ[45] CMOS I/O
H30 VSS GND
H31 RSVD
H32 RSVD
H33 DDR1_DQ[24] CMOS I/O
H34 DDR1_DQ[29] CMOS I/O
H35 VSS GND
H36 DDR1_DQ[23] CMOS I/O
H37 DDR2_DQ[27] CMOS I/O
H38 RSVD
H39 DDR2_DQ[28] CMOS I/O
H4 DDR1_DQ[43] CMOS I/O
H40 VSS GND
Table 4-2. Land Listing by Land Number
(Sheet 26 of 36)
Land
No.
Pin Name
Buffer
Type
Direction
