Intel Core i7 Extreme Edition - Page 68

Land Listing
68 Datasheet
H41 DDR0_DQ[16] CMOS I/O
H42 RSVD
H43 DDR0_DQ[17] CMOS I/O
H5 VSS GND
H6 DDR1_DQS_P[5] CMOS I/O
H7 RSVD
H8 DDR1_DQ[40] CMOS I/O
H9 DDR1_DQ[45] CMOS I/O
J1 RSVD
J10 DDR2_DQS_P[4] CMOS I/O
J11 RSVD
J12 DDR2_DQ[33] CMOS I/O
J13 VSS GND
J14 DDR1_MA[0] CMOS O
J15 RSVD
J16 DDR1_MA[1] CMOS O
J17 DDR1_MA[2] CMOS O
J18 VDDQ PWR
J19 DDR0_CLK_P[0] CLOCK O
J2 RSVD
J20 DDR2_MA[3] CMOS O
J21 DDR2_CLK_N[0] CLOCK O
J22 DDR2_CLK_P[0] CLOCK O
J23 VDDQ PWR
J24 DDR2_MA[7] CMOS O
J25 RSVD
J26 DDR2_CKE[0] CMOS O
J27 DDR1_MA[6] CMOS O
J28 VDDQ PWR
J29 RSVD
J3 VSS GND
J30 RSVD
J31 RSVD
J32 DDR1_DQ[27] CMOS I/O
J33 VSS GND
J34 DDR1_DQ[28] CMOS I/O
J35 DDR1_DQ[19] CMOS I/O
J36 DDR1_DQ[22] CMOS I/O
J37 DDR2_DQ[26] CMOS I/O
Table 4-2. Land Listing by Land Number
(Sheet 27 of 36)
Land
No.
Pin Name
Buffer
Type
Direction
J38 VSS GND
J39 DDR2_DQ[19] CMOS I/O
J4 DDR1_DQ[52] CMOS I/O
J40 DDR2_DQ[18] CMOS I/O
J41 DDR0_DQ[21] CMOS I/O
J42 DDR0_DQ[20] CMOS I/O
J43 VSS GND
J5 DDR1_DQ[47] CMOS I/O
J6 DDR1_DQ[41] CMOS I/O
J7 RSVD
J8 VSS GND
J9 DDR2_DQS_N[4] CMOS I/O
K1 VSS GND
K10 DDR2_DQ[41] CMOS I/O
K11 VSS GND
K12 DDR2_DQ[32] CMOS I/O
K13 DDR1_BA[1] CMOS O
K14 DDR2_CS#[1] CMOS O
K15 RSVD
K16 VDDQ PWR
K17 DDR2_MA[1] CMOS O
K18 DDR1_CLK_P[2] CLOCK O
K19 DDR0_CLK_N[0] CLOCK O
K2 DDR0_DQS_P[5] CMOS I/O
K20 DDR2_CLK_N[1] CLOCK O
K21 VDDQ PWR
K22 DDR2_MA[6] CMOS O
K23 DDR2_MA[5] CMOS O
K24 RSVD
K25 RSVD
K26 VDDQ PWR
K27 RSVD
K28 DDR1_MA[4] CMOS O
K29 RSVD
K3 DDR0_DQS_N[5] CMOS I/O
K30 DDR1_DQ[31] CMOS I/O
K31 VSS GND
K32 DDR1_DQ[26] CMOS I/O
K33 RSVD
Table 4-2. Land Listing by Land Number
(Sheet 28 of 36)
Land
No.
Pin Name
Buffer
Type
Direction
