Land Listing
Datasheet 69
K34 RSVD
K35 DDR1_DQ[18] CMOS I/O
K36 VSS GND
K37 RSVD
K38 DDR2_DQ[23] CMOS I/O
K39 DDR2_DQS_N[2] CMOS I/O
K4 DDR1_DQ[48] CMOS I/O
K40 DDR2_DQS_P[2] CMOS I/O
K41 VSS GND
K42 DDR0_DQ[10] CMOS I/O
K43 DDR0_DQ[11] CMOS I/O
K5 DDR1_DQ[49] CMOS I/O
K6 VSS GND
K7 DDR2_DQS_N[5] CMOS I/O
K8 RSVD
K9 RSVD
L1 DDR0_DQ[42] CMOS I/O
L10 DDR2_DQ[40] CMOS I/O
L11 DDR2_DQ[44] CMOS I/O
L12 DDR2_DQ[39] CMOS I/O
L13 DDR2_DQ[35] CMOS I/O
L14 VDDQ PWR
L15 RSVD
L16 DDR2_ODT[0] CMOS O
L17 RSVD
L18 DDR1_CLK_N[2] CLOCK O
L19 VDDQ PWR
L2 DDR0_DQ[47] CMOS I/O
L20 DDR2_CLK_P[1] CLOCK O
L21 DDR2_CLK_N[3] CLOCK O
L22 DDR2_CLK_P[3] CLOCK O
L23 DDR_VREF Analog I
L24 VDDQ PWR
L25 DDR2_MA[8] CMOS O
L26 DDR2_BA[2] CMOS O
L27 DDR2_CKE[3] CMOS O
L28 DDR1_MA[3] CMOS O
L29 VSS GND
L3 DDR0_DQ[46] CMOS I/O
Table 4-2. Land Listing by Land Number
(Sheet 29 of 36)
Land
No.
Pin Name
Buffer
Type
Direction
L30 DDR1_DQS_P[3] CMOS I/O
L31 DDR1_DQS_N[3] CMOS I/O
L32 DDR1_DQ[30] CMOS I/O
L33 DDR1_DQ[25] CMOS I/O
L34 VSS GND
L35 DDR1_DQS_P[2] CMOS I/O
L36 DDR1_DQS_N[2] CMOS I/O
L37 RSVD
L38 RSVD
L39 VSS GND
L4 VSS GND
L40 DDR2_DQ[22] CMOS I/O
L41 DDR0_DQS_P[1] CMOS I/O
L42 DDR0_DQ[15] CMOS I/O
L43 DDR0_DQ[14] CMOS I/O
L5 DDR1_DQS_N[6] CMOS I/O
L6 DDR1_DQS_P[6] CMOS I/O
L7 DDR2_DQS_P[5] CMOS I/O
L8 DDR2_DQ[46] CMOS I/O
L9 VSS GND
M1 DDR0_DQ[43] CMOS I/O
M10 DDR2_DQ[45] CMOS I/O
M11 VCC PWR
M12 VSS GND
M13 VCC PWR
M14 VSS GND
M15 VCC PWR
M16 VSS GND
M17 VDDQ PWR
M18 VSS GND
M19 VCC PWR
M2 VSS GND
M20 VSS GND
M21 VCC PWR
M22 VSS GND
M23 VCC PWR
M24 VSS GND
M25 VCC PWR
M26 VSS GND
Table 4-2. Land Listing by Land Number
(Sheet 30 of 36)
Land
No.
Pin Name
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
