Land Listing
Datasheet 71
R38 DDR1_DQS_P[1] CMOS I/O
R39 DDR2_DQ[10] CMOS I/O
R4 DDR0_DQ[54] CMOS I/O
R40 DDR2_DQ[15] CMOS I/O
R41 VSS GND
R42 DDR0_DQ[3] CMOS I/O
R43 DDR0_DQ[2] CMOS I/O
R5 DDR1_DQ[50] CMOS I/O
R6 VSS GND
R7 DDR1_DQ[55] CMOS I/O
R8 DDR1_DQ[54] CMOS I/O
R9 DDR2_DQ[55] CMOS I/O
T1 DDR0_DQ[50] CMOS I/O
T10 DDR2_DQ[58] CMOS I/O
T11 VCC PWR
T2 DDR0_DQ[51] CMOS I/O
T3 DDR0_DQ[55] CMOS I/O
T33 VCC PWR
T34 VSS GND
T35 RSVD
T36 DDR2_DQ[11] CMOS I/O
T37 DDR2_DQS_P[1] CMOS I/O
T38 DDR2_DQS_N[1] CMOS I/O
T39 VSS GND
T4 VSS GND
T40 RSVD
T41 DDR2_DQ[14] CMOS I/O
T42 DDR0_DQ[7] CMOS I/O
T43 DDR0_DQS_P[0] CMOS I/O
T5 DDR1_DQ[51] CMOS I/O
T6 DDR2_DQ[60] CMOS I/O
T7 DDR2_DQ[61] CMOS I/O
T8 DDR2_DQS_N[7] CMOS I/O
T9 VSS GND
U1 DDR0_DQ[60] CMOS I/O
U10 DDR2_DQ[59] CMOS I/O
U11 RSVD
U2 VSS GND
U3 DDR0_DQ[61] CMOS I/O
Table 4-2. Land Listing by Land Number
(Sheet 33 of 36)
Land
No.
Pin Name
Buffer
Type
Direction
U33 VCCPLL PWR
U34 DDR2_DQ[4] CMOS I/O
U35 RSVD
U36 DDR2_DQ[3] CMOS I/O
U37 VSS GND
U38 DDR2_DQ[8] CMOS I/O
U39 DDR2_DQ[9] CMOS I/O
U4 DDR0_DQ[56] CMOS I/O
U40 RSVD
U41 DDR0_DQ[6] CMOS I/O
U42 VSS GND
U43 DDR0_DQS_N[0] CMOS I/O
U5 DDR2_DQ[56] CMOS I/O
U6 DDR2_DQ[57] CMOS I/O
U7 VSS GND
U8 DDR2_DQS_P[7] CMOS I/O
U9 DDR2_DQ[63] CMOS I/O
V1 DDR0_DQ[57] CMOS I/O
V10 VSS GND
V11 RSVD
V2 RSVD
V3 RSVD
V33 VCCPLL PWR
V34 DDR2_DQ[5] CMOS I/O
V35 VSS GND
V36 DDR2_DQ[2] CMOS I/O
V37 DDR2_DQ[6] CMOS I/O
V38 DDR2_DQ[7] CMOS I/O
V39 DDR2_DQ[13] CMOS I/O
V4 DDR0_DQ[62] CMOS I/O
V40 VSS GND
V41 DDR0_DQ[1] CMOS I/O
V42 RSVD
V43 RSVD
V5 VSS GND
V6 RSVD
V7 RSVD
V8 DDR2_DQ[62] CMOS I/O
V9 DDR1_DQ[60] CMOS I/O
Table 4-2. Land Listing by Land Number
(Sheet 34 of 36)
Land
No.
Pin Name
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
