Land Listing
72 Datasheet
§
W1 DDR0_DQS_N[7] CMOS I/O
W10 DDR1_DQ[59] CMOS I/O
W11 VCC PWR
W2 DDR0_DQS_P[7] CMOS I/O
W3 VSS GND
W33 VCCPLL PWR
W34 DDR2_DQ[0] CMOS I/O
W35 DDR2_DQ[1] CMOS I/O
W36 DDR2_DQS_N[0] CMOS I/O
W37 DDR2_DQS_P[0] CMOS I/O
W38 VSS GND
W39 DDR2_DQ[12] CMOS I/O
W4 DDR0_DQ[63] CMOS I/O
W40 DDR0_DQ[4] CMOS I/O
W41 DDR0_DQ[0] CMOS I/O
W42 DDR0_DQ[5] CMOS I/O
W43 VSS GND
W5 DDR1_DQ[61] CMOS I/O
W6 DDR1_DQ[56] CMOS I/O
W7 DDR1_DQ[57] CMOS I/O
W8 VSS GND
W9 DDR1_DQ[63] CMOS I/O
Table 4-2. Land Listing by Land Number
(Sheet 35 of 36)
Land
No.
Pin Name
Buffer
Type
Direction
Y1 VSS GND
Y10 DDR1_DQ[58] CMOS I/O
Y11 VSS GND
Y2 DDR0_DQ[58] CMOS I/O
Y3 DDR0_DQ[59] CMOS I/O
Y33 VSS GND
Y34 DDR1_DQ[3] CMOS I/O
Y35 DDR1_DQ[2] CMOS I/O
Y36 VSS GND
Y37 DDR1_DQS_N[0] CMOS I/O
Y38 DDR1_DQS_P[0] CMOS I/O
Y39 DDR1_DQ[7] CMOS I/O
Y4 RSVD
Y40 DDR1_DQ[6] CMOS I/O
Y41 VSS GND
Y5 RSVD
Y6 VSS GND
Y7 DDR_COMP[1] Analog
Y8 DDR1_DQS_P[7] CMOS I/O
Y9 DDR1_DQS_N[7] CMOS I/O
Table 4-2. Land Listing by Land Number
(Sheet 36 of 36)
Land
No.
Pin Name
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
