(6) PWRLED (3-pin): Power LED Header
PWRLED
Pin 1
PWRLE D+
PWRLED-
PWRLED-
(7) SPEAK (9-pin): Speaker Header
SPEAK
SPK +
NC
SPK -
Pin 1
NC
