(8) JW-FP1 (9-pin): Front Panel Header
HDLED
RESET
HDDLED+
GND
PWRLED+
PWRBTN
GND
PWRLED-
HDDLED-
RSTSW
V
CC5
PWRBT N
Pin 1
2
PWR LED
(9) LVDS (30-Pin): 18-bit single channel LVDS Header
Pin2
LVDS Header
Pin 1 Pin 29
Pin 30
