Intel Desktop Board D915GLVG Technical Product Specification
10
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the board.
Table 1. Feature Summary
Form Factor
microATX (9.60 inches by 9.60 inches [243.84 millimeters by 243.84 millimeters])
Processor
Support for an Intel
®
Pentium
®
4 processor in an LGA775 socket with an 800 or
533 MHz system bus
Memory
• Four DDR SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR 400 MHz and DDR 333 MHz DIMMs
• Support for up to 4 GB of system memory
Chipset
Intel
®
915GL Chipset, consisting of:
• Intel
®
82915GL Graphics Memory Controller Hub (GMCH)
• Intel
®
82801FB I/O Controller Hub (ICH6)
• 4 Mbit Firmware Hub (FWH)
Video
Intel
®
GMA900 onboard graphics subsystem
Audio
Intel
®
High Definition Audio subsystem using the Realtek ALC860 audio codec
I/O Control
LPC Bus I/O controller
USB
Support for USB 2.0 devices
Peripheral
Interfaces
• Eight USB ports
• One serial port
• One parallel port
• Four Serial ATA interfaces
• One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support
• One diskette drive interface
• PS/2* keyboard and mouse ports
LAN Support
10/100 Mbits/sec LAN subsystem using the Intel
®
82562GZ Platform LAN Connect
(PLC) device
BIOS
• Intel/AMI BIOS (resident in the 4 Mbit FWH)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
continued
