Intel Desktop Board D915GLVG T
echnical Product Specification
50
Table 18.
Chassis Intrusion Connector
Pin Signal
Name
1 Intruder
2 Ground
Table 19.
Serial ATA Connectors
Pin Signal
Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 20.
Processor Fan Connector
Pin Signal
Name
1 Ground
2 +12
V
3 FAN_TACH
4 FAN_CONTROL
Table 21.
Chassis Fan Connectors
Pin Signal
Name
1 Control
2
+
12 V
3 Tach
49
51
