Product Description
23
1.5.1.1 Dynamic Video Memory Technology (DVMT)
DVMT enables enhanced graphics and memory performance through Direct AGP, and highly
efficient memory utilization. DVMT ensures the most efficient use of available system memory for
maximum 2-D/3-D graphics performance. Up to 224 MB of system memory can be allocated to
DVMT on systems that have 512 MB or more of total system memory installed. Up to 128 MB can
be allocated to DVMT on systems that have 256 MB but less than 512 MB of total installed system
memory. Up to 64 MB can be allocated to DVMT when less than 256 MB of system memory is
installed. DVMT returns system memory back to the operating system when the additional system
memory is no longer required by the graphics subsystem.
DVMT will always use a minimal fixed portion of system physical memory (as set in the BIOS
Setup program) for compatibility with legacy applications. An example of this would be when
using VGA graphics under DOS. Once loaded, the operating system and graphics drivers allocate
additional system memory to the graphics buffer as needed for performing graphics functions.
NOTE
The use of DVMT requires operating system driver support.
1.5.1.2 Configuration Modes
A list of supported modes for the Intel GMA900 graphics controller is available as a downloadable
document.
For information about Refer to
Supported modes for the D915GLVG
board
http://www.intel.com/design/motherbd/vg/vg_documentation.htm
1.5.2 USB
The boards support up to eight USB 2.0 ports, supports UHCI and EHCI, and uses UHCI- and
EHCI-compatible drivers.
The ICH6 provides the USB controller for all ports. The port arrangement is as follows:
• Four ports are implemented with dual stacked back panel connectors adjacent to the audio
connectors
• Four ports are routed to two separate front panel USB connectors
NOTE
Computer systems that have an unshielded cable attached to a USB port may not meet FCC
Class B requirements, even if no device is attached to the cable. Use shielded cable that meets the
requirements for full-speed devices.
For information about Refer to
The location of the USB connectors on the back panel Figure 15, page 47
The location of the front panel USB connectors Figure 16, page 48
