Product Description
13
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1
Description
A
Realtek ALC860 audio codec
B
Front panel audio connector
C
PCI Conventional bus add-in card connectors
D
Ethernet PLC device
E
Rear chassis fan connector
F
Back panel connectors
G
+12V power connector (ATX12V)
H
LGA775 processor socket
I
Hardware monitoring and fan control ASIC
J
Processor fan connector
K
Intel
82915GL GMCH
L
DIMM Channel A sockets
M
DIMM Channel B sockets
N
I/O controller
O
Power connector
P
Diskette drive connector
Q
Parallel ATE IDE connector
R
Battery
S
Chassis intrusion connector
T
BIOS Setup configuration jumper block
U
4 Mbit Firmware Hub (FWH)
V
Front chassis fan connector
W
Serial ATA connectors
X
Auxiliary front panel power LED connector
Y
Front panel connector
Z
Front panel USB connectors
AA
Intel
82801FB I/O Controller Hub (ICH6)
BB
Speaker
CC
PCI Express x1 bus add-in card connector
