Intel Desktop Board D946GZIS Product Guide
12
Table 2. Desktop Board D946GZIS Components
Label Description
A HD Audio Link header
B PCI bus connector 2
C Front panel audio header
D PCI bus connector 1
E PCI Express x1 connector
F PCI Express x16 connector
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin )
I Rear chassis fan header (3-pin)
J Processor socket
K Processor fan header (4-pin)
L DIMM 0 Channel A socket
M DIMM 0, Channel B socket
N Main power connector (2 x 12 pin)
O Diskette drive connector
P IDE connector
Q Battery
R Front chassis fan header (3-pin)
S Chassis intrusion header
T Alternate front panel power LED header
U Front panel header
V Serial ATA connectors
W Hi-speed USB 2.0 headers
X Speaker
Y BIOS configuration jumper block
Related Links:
Go to the following links for more information about:
• Desktop Board D946GZIS
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd

Intel D946GZIS - Desktop Board Motherboard Specifications

General

Form Factor	ATX
Chipset	Intel 946GZ
Processor Support	Intel Core 2 Duo, Pentium D, Pentium 4, Celeron D
Socket Type	LGA 775
Memory Type	DDR2
Memory Slots	4
Maximum Memory	4 GB
Expansion Slots	1 x PCIe x16, 2 x PCIe x1, 3 x PCI
Integrated Graphics	Intel Graphics Media Accelerator 3000
USB Ports	8 x USB 2.0
Video Outputs	VGA
LAN	10/100/1000 Mbps
Storage Interfaces	4 x SATA 3.0 Gb/s, 1 x PATA
