Desktop Board Features
15
Back panel audio connectors that are configurable through the audio device
drivers:
Line in/retasking jack
Line out/retasking jack
Mic in/retasking jack
Related Links:
Go to the following link or pages for more information about:
Audio drivers and utilities
http://support.intel.com/support/motherboards/desktop/
Installing the front panel audio solution, page
41
The location of audio connectors,
Figure 21 on page 44
Input/Output (I/O) Controller
The super I/O controller features the following:
One serial port
One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) support
Serial IRQ interface compatible with serialized IRQ support for PCI systems
PS/2-style mouse and keyboard interfaces
Interface for one 1.2 MB or 1.44 MB diskette drive
Intelligent power management, including a programmable wake up event interface
PCI power management support
LAN Subsystem
The LAN subsystem consists of the following:
Intel
®
82562G Platform LAN Connect (PLC) device for 10/100 Mb/s Ethernet LAN
connectivity
RJ-45 connector with status indicator LEDs
LAN Subsystem Software
For LAN software and drivers, refer to the D946GZIS link on Intel’s World Wide Web
site at:
http://support.intel.com/support/motherboards/desktop
