Intel Desktop Board D946GZIS Product Guide
26
Installing and Removing the Desktop Board
CAUTION
Only qualified technical personnel should do this procedure. Disconnect the computer
from its power source before performing the procedures described here. Failure to
disconnect the power before you open the computer can result in personal injury or
equipment damage.
Refer to your chassis manual for instructions on installing and removing the desktop
board.
Figure 5 shows the location of the mounting screw holes for Desktop Board D946GZIS.
Figure 5. Desktop Board D946GZIS Mounting Screw Hole Locations

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel D946GZIS - Desktop Board Motherboard and is the answer not in the manual?

Intel D946GZIS - Desktop Board Motherboard Specifications

General IconGeneral
Form FactorATX
ChipsetIntel 946GZ
Processor SupportIntel Core 2 Duo, Pentium D, Pentium 4, Celeron D
Socket TypeLGA 775
Memory TypeDDR2
Memory Slots4
Maximum Memory4 GB
Expansion Slots1 x PCIe x16, 2 x PCIe x1, 3 x PCI
Integrated GraphicsIntel Graphics Media Accelerator 3000
USB Ports8 x USB 2.0
Video OutputsVGA
LAN10/100/1000 Mbps
Storage Interfaces4 x SATA 3.0 Gb/s, 1 x PATA
