Intel DG33BU User Manual

Product Description
13
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Descri
ption
A PCI Conventional bus add-in card connector 1
B Front panel audio header
C PCI Conventional bus add-in card connector 2
D PCI Express x1 connector
E Speaker
F PCI Express x16 connector
G Back panel connectors
H Processor core power connector (2 X 2)
I Rear chassis fan header
J LGA775 processor socket
K Intel 82G33 GMCH
L Processor fan header
M DIMM Channel A sockets
N Serial port header
O DIMM Channel B sockets
P Main Power connector (2 X 12)
Q Diskette drive connector
R Chassis intrusion header
S Battery
T Front chassis fan header
U Intel 82801IH I/O Controller Hub (ICH9DH)
V BIOS Setup configuration jumper block
W Auxiliary front panel power LED header
X Front panel header
Y Serial ATA connectors [4]
Z Front panel USB headers [3]
AA Parallel ATA IDE connector
BB IEEE 1394a header

Intel DG33BU Specifications

General

Form Factor	ATX
Chipset	Intel G33
Socket	LGA 775
Memory Type	DDR2
Maximum Memory	8 GB
Memory Slots	4
Supported CPU	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Expansion Slots	1 x PCI Express x16, 3 x PCI
USB Ports	8 x USB 2.0
Audio	Realtek ALC888 HD Audio
LAN	Intel 82566DC Gigabit Ethernet
Video Outputs	VGA
Memory Standard	DDR2 667/800
SATA Ports	4 x SATA 3Gb/s
