Intel Desktop Board DG33BU Technical Product Specification
78
Table 40 shows the various forms of the “Lead-Free 2
nd
Level Interconnect” mark as it
appears on the board and accompanying collateral.
Table 40. Lead-Free Board Markings
Description Mark
Lead-Free 2
nd
Level
Interconnect: This symbol is
used to identify electrical and
electronic assemblies and
components in which the lead
(Pb) concentration level in the
desktop board substrate and the
solder connections from the board
to the components (second-level
interconnect) is not greater than
0.1% by weight (1000 ppm).
or
or

Intel DG33BU Specifications

General

Form Factor	ATX
Chipset	Intel G33
Socket	LGA 775
Memory Type	DDR2
Maximum Memory	8 GB
Memory Slots	4
Supported CPU	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Expansion Slots	1 x PCI Express x16, 3 x PCI
USB Ports	8 x USB 2.0
Audio	Realtek ALC888 HD Audio
LAN	Intel 82566DC Gigabit Ethernet
Video Outputs	VGA
Memory Standard	DDR2 667/800
SATA Ports	4 x SATA 3Gb/s
