Technical Reference
43
Table 10 lists the component-side connectors and headers identified in Figure 10.
Table 10. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10
Descri
ption
A PCI Conventional bus add-in card connector 1
B Front panel audio header
C PCI Conventional bus add-in card connector 2
D PCI Express x1 connector
E PCI Express x16 connector
F Processor core power connector (2 X 2)
G Rear chassis fan header
H Processor fan header
I Serial port header
J Main power connector (2 X 12)
K Diskette drive connector
L Chassis intrusion header
M Front chassis fan header
N Auxiliary front panel power LED header
O Front panel header
P Serial ATA connectors [4]
Q Front panel USB header
R Front panel USB header
S Front panel USB header
T Parallel ATA IDE connector
U IEEE 1394a header

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel DG33BU and is the answer not in the manual?

Intel DG33BU Specifications

General IconGeneral
Form FactorATX
ChipsetIntel G33
SocketLGA 775
Memory TypeDDR2
Maximum Memory8 GB
Memory Slots4
Supported CPUIntel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Expansion Slots1 x PCI Express x16, 3 x PCI
USB Ports8 x USB 2.0
AudioRealtek ALC888 HD Audio
LANIntel 82566DC Gigabit Ethernet
Video OutputsVGA
Memory StandardDDR2 667/800
SATA Ports4 x SATA 3Gb/s
