Technical Reference

2.2.1 Back Panel Connectors

Figure 9 shows the locations of the back panel connectors.

Item Description

A PS/2 mouse port

B PS/2 keyboard port

C VGA port

D IEEE 1394a port

E USB ports [2]

F USB ports [2]

G LAN

H USB ports [2]

I Line in

J Mic in

K Line out

Figure 9. Back Panel Connectors

Questions and Answers:

Need help?

Do you have a question about the Intel DG33BU and is the answer not in the manual?

General

Form Factor	ATX
Chipset	Intel G33
Socket	LGA 775
Memory Type	DDR2
Maximum Memory	8 GB
Memory Slots	4
Supported CPU	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Expansion Slots	1 x PCI Express x16, 3 x PCI
USB Ports	8 x USB 2.0
Audio	Realtek ALC888 HD Audio
LAN	Intel 82566DC Gigabit Ethernet
Video Outputs	VGA
Memory Standard	DDR2 667/800
SATA Ports	4 x SATA 3Gb/s
