Intel Desktop Board DG45ID Technical Product Specification
10
Table 1. Feature Summary (continued)
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.3
• Support for PCI Express* Revision 1.0a
• Suspend to RAM support
• Wake on PCI, RS-232, front panel, USB ports, LAN, and CIR
Expansion
Capabilities
• One PCI Express 2.0 x16 bus add-in card connector
• Two PCI Express x1 bus add-in card connectors
• One PCI Conventional bus connector
Hardware Monitor
Subsystem
• Intel
®
Quiet System Technology implemented through the Intel
®
Management
Engine (Intel
®
MEI) in ICH10R
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Three fan sense inputs used to monitor fan activity
