Technical Reference
49
Table 17. Chassis Intrusion Header
Pin Signal
Name
1 Intruder
2 Ground
Table 18. Front and Rear Chassis (3-Pin) Fan Headers
Pin Signal
Name
1 Control
2 +12
V
3 Tach
Table 19. Processor (4-Pin) Fan Header
Pin Signal
Name
1 Ground
2 +12
V
3 FAN_TACH
4 FAN_CONTROL
Table 20. Back Panel CIR Emitter (Output) Header
Pin Signal
Name
1
Emitter o
ut 1
2
Emitter o
ut 2
3 Ground
4
Key (no pin)
5
Jack detect 1
6
Jack detect 2
Table 21. Front Panel CIR Receiver (Input) Header
Pin Signal
Name
1 Ground
2 LED
3 NC
4 Learn-in
5
5 V standby
6 VCC
7
Key (no pin)
8 CIR
Input
48
50
