Intel Desktop Board DG45ID Technical Product Specification
16
1.5 System Memory
The board has four DIMM sockets and support the following memory features:
• 1.8 V DDR2 SDRAM DIMMs with gold plated contacts, with the option to raise the
voltage to support higher performance DDR2 SDRAM DIMMs
• Dual channel interleaved mode support
• Unbuffered, single-sided or double-sided DIMMs with the following restriction:
Double-sided DIMMs with x16 organization are not supported.
• 8 GB maximum total system memory using DDR2 800 or DDR2 667 DIMMs; refer
to Section 2.1.1 on page 41 for information on the total amount of addressable
memory.
• Minimum recommended total system memory: 512 MB
• Non-ECC DIMMs
• Serial Presence Detect
• DDR2 800 MHz or DDR2 667 MHz SDRAM DIMMs
• DDR2 667 MHz DIMMs with SPD timings of only 5-5-5 (tCL-tRCD-tRP)
• DDR2 800 MHz DIMMs with SPD timings of only 5-5-5 or 6-6-6 (tCL-tRCD-tRP)
NOTE
To be fully compliant with all applicable DDR SDRAM memory specifications, the board
should be populated with DIMMs that support the Serial Presence Detect (SPD) data
structure. This allows the BIOS to read the SPD data and program the chipset to
accurately configure memory settings for optimum performance. If non-SPD memory
is installed, the BIOS will attempt to correctly configure the memory settings, but
performance and reliability may be impacted or the DIMMs may not function under the
determined frequency.
Table 3. Supported Memory Configurations
DIMM
Type
SDRAM
Technology
Smallest usable
DIMM (one x16
Single-sided
DIMM)
Largest usable
DIMM (one x8
Double-sided
DIMM)
Maximum capacity
with four identical
x8 Double-sided
DIMMs
DDR2 667 512 Mbit 256 MB 1 GB 4 GB
DDR2 667 1 Gbit 512 MB 2 GB 8 GB
DDR2 800 512 Mbit 256 MB 1 GB 4 GB
DDR2 800 1 Gbit 512 MB 2 GB 8 GB
For information about… Refer to:
Tested Memory http://support.intel.com/support/motherboards/desktop/sb/
CS-025414.htm
