Intel Desktop Board DG45ID Technical Product Specification
48
2.2.2.1 Signal Tables for the Connectors and Headers
Table 13. HD Audio Link Header
Pin Signal Name Pin Signal Name
1 BCLK 2 Ground
3 RST# 4 DVDD IO
5 SYNC 6 Ground
7 SDO 8 3.3 V DVDD CORE
9 SDI0 10 +12 V
11 SDI1 12 Key (no pin)
13 Not connected 14 3.3 V DUAL
15 Not connected 16 Ground
Table 14. Front Panel Audio Header
Pin Signal Name Pin Signal Name
1 [Port 1] Left channel 2 Ground
3 [Port 1] Right channel 4 PRESENCE# (Dongle present)
5 [Port 2] Right channel 6 [Port 1] SENSE_RETURN
7 SENSE_SEND (Jack detection) 8 Key (no pin)
9 [Port 2] Left channel 10 [Port 2] SENSE_RETURN
Table 15. Serial ATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 16. Serial Port Header
Pin Signal Name Pin Signal Name
1 DCD (Data Carrier Detect) 2 RXD# (Receive Data)
3 TXD# (Transmit Data) 4 DTR (Data Terminal Ready)
5 Ground 6 DSR (Data Set Ready)
7 RTS (Request to Send) 8 CTS (Clear to Send)
9 RI (Ring Indicator) 10 Key (no pin)
