Intel Desktop Board DG45ID Technical Product Specification
12
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Descri
ption
A Front panel audio header
B PCI Conventional bus add-in card connector
C PCI Express x1 connector
D PCI Express x16 connector
E PCI Express x1 connector
F Rear chassis fan connector
G Back panel connectors
H Back panel CIR emitter (output) header
I Processor core power connector (2 X 2)
J Serial port header
K LGA775 processor socket
L Processor fan header
M DIMM Channel A sockets
N DIMM Channel B sockets
O Front panel CIR receiver (input) header
P Main Power connector (2 X 12)
Q Front chassis fan header
R Chassis intrusion header
S Battery
T Auxiliary front panel power LED header
U Front panel header
V BIOS Setup configuration jumper block
W Serial ATA connectors [5]
X Speaker
Y Intel 82801JR I/O Controller Hub (ICH10R)
Z Front panel USB header
AA Intel 82G45 GMCH
BB Front panel USB header
CC Front panel USB header
DD IEEE-1394a header
EE High Definition Audio Link header
FF S/PDIF connector
