Heatsink Clip Load Metrology

Thermal and Mechanical Design Guidelines 83

Figure 7-9. Load Cell Installation in Machined Heatsink Base Pocket – Side View

Figure 7-10. Preload Test Configuration

Load Cells (3x)

Preload Fixture (copper

core with milled out pocket)

Wax to maintain load cell in

position during heatsink

installation

Height of pocket

~ height of

selected load

cell

Load cell protrusion

(Note: to be optimized depending on

assembly stiffness)
