2-14 PRO/100 LAN+Modem PC Card User’s Guide
There are user-configurable parameters for the M16B.SYS driver that can
be modified using the Network Control Panel applet built into Windows
95. This applet queries the user for parameter selections and then sets the
corresponding parameters in the registry. The user-configurable param-
eters are as follows:
Parameter Default Valid Values Registry Value
DIRECT ENABLE OFF OFF, ON 0
EARLY TRANSMIT ON OFF 0
ON 1
FULL DUPLEX OFF OFF 0
ON 1
FUNCTION(S) NETWORK&MODEM
NETWORK&MODEM 0
NETWORK ONLY 1
MODEM ONLY 2
LINE SPEED AUTO AUTO DETECT 0
10MBPS 1
100MBPS 2
LINK INTEGRITY ON OFF 0
ON 1
MODE I/O I/O 0
MEMORY MAPPED 1
NETWORKADDRESS
TRANSMITBUFFERSIZE 7168 1024-29696 1024-29696
The network node address can be modified by specifying a value for
NetworkAddress such as 00A0C9112233. If the user does NOT specify
a NetworkAddress then the M16B.SYS driver uses the network node
address contained in the PRO/100 Card information structure.
There are parameters in the Windows 95 registry which specify the
configuration of the EtherExpress PRO/100 LAN+Modem PC Card
hardware to the M16B.SYS driver. Many of these parameters correspond
directly to the user-configurable parameters. These parameters are found
in the registry at the following location:
HKEY_LOCAL_MACHINE\SYSTEM\CURRENTCONTROLSET\SERVICES\CLASS\NET\000X
