4-40 PRO/100 LAN+Modem PC Card User’s Guide
NDIS 2.0.1 Settings (for driver
M16BNDIS.EXE)
Custom parameters for the NDIS driver can be entered manually, using an
ASCII editor, in the PROTOCOL.INI file.
NDIS 2.0.1 DOS Driver Configuration Notes
The DOS NDIS driver M16BNDIS.EXE conforms to the Microsoft
Network Driver Interface Specification (NDIS) version 2.0.1. It is a DOS-
based executable terminate-and-stay-resident (TSR) program that will
configure itself according to the options specified in the PROTOCOL.INI
file, which is supplied on Disk 2. Network Drivers Disk.
The files required for using M16BNDIS.EXE are:
PROTOCOL.INI Configuration and binding informa
tion file
M16BDOS.NIF Intel installation file for Microsoft
LAN Manager
M16BNDIS.EXE Intel DOS NDIS 2.0.1 driver
Most installations will be able to use the settings detected by the driver. If
any parameters need to be changed, use an ASCII text editor to modify
the PROTOCOL.INI file with the appropriate keywords and values.
Keyword syntax for PROTOCOL.INI can be found below. Keywords are
not case sensitive, and can be abbreviated to a unique sequence of initial
characters (for example, IN for INTERRUPT, IO for IOADDRESS). A
Keyword Alphabetical Reference follows the keyword listings.
PROTOCOL.INI Example
[INTELNET]
DRIVERNAME=INTEL
MEM=0XD2000
MODE=IO
To Next Page
