Intel G31 Series User Manual

- 14 -
G31 Series User's Manual
JG31C0 2 V1.1
185*24 3.8MM
LP T
3.8 S/PDIF Output Connection Header
S/PDIF (Sony/Philips Digital Interface) is a standard audio transfer le format. It is usually
found on digital audio equipment such as a DAT (Digital Audio Tape) machine or audio
processing device. It allows the transfer of audio from one le to another without the
conversion to and from an analog format, which could degrade the signal quality.
1
3
GNDVCC OUT

Intel G31 Series Specifications

General

Socket	LGA 775
Maximum Memory	4 GB
Southbridge	Intel ICH7
SATA Speed	3Gb/s
Graphics Output	VGA
Chipset	Intel G31
Memory Type	DDR2
Graphics	Intel GMA 3100
PCI Express Slots	1 x PCIe x16
SATA Ports	4
USB Ports	8
Northbridge	Intel G31
Supported CPU	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Memory Slots	2
IDE	1 x ATA-100
LAN	Realtek RTL8111B
FSB	1333 MHz
Memory Types	DDR2 800/667 MHz
