- 29 -
G31 Series User's Manual
4.5.7 Power setting
・
Suspend mode
Optional: Auto, S1(POS), S3(STR)
S1(POS): Enables the system to enter the ACPI S1(Power on Suspend)sleep state(default),
In S1 sleep state, the system appears suspended any stays in a low power mode.
The system can be resumed at any time.
S3(STR): Ehables the system to enter the ACPI S3(Suspend to RAM)sleep state. In S3 sleep
state. When signaled by a wake-up device or event, the system resumes to its
working state exactly where it was left off.
・
Repost Video on S3 Resume
Determines whether to invoke VGA BIOS post on S3/STR resume.
Optional: Yes, No
・
ACPI Version Features
Enable RSDP pointers to 64-bit xed system description tables.
Optional: ACPI v1.0, ACPI v2.0, ACPI v3.0
・
ACPI APIC support
Allows you to enable or disable the Advanced Conguration and Power Interface (ACPI)
support in the Advanced Programmable Interrupt Controller (APIC) . When set to [Enabled],
the ACPI APIC table pointer is included in the RSDT pointer list.
Optional: Enabled, Desabled
・
High Performance Event Timer
The item allows enable or disable HPET.
Optional: Enabled, Desabled
・
Press <Esc> key to return to "Power" menu.
►
ACPI Conguration
Click <Press Enter> key to enter its submenu.
BIOS SETUP UTILITY
Main Advanced Boot Security Power JUSTw00t! Exit
Power Settings Section for Advanced
ACPI Configuration.
←
Select Screen
↑↓
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
►
ACPI Configuration
►
APM Configuration
►
PC Health
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
BIOS SETUP UTILITY
Power
ACPI Settings Select the ACPI
state used for
System Suspend.
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Suspend mode
Repost Video on S3 Resume
ACPI Verion Features
ACPI APIC support
High Performance Event Timer
[Auto]
[No]
[ACPI v1.0]
[Enabled]
[Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
