- 31 -
G31 Series User's Manual
・
All Voltages, Fans Speed and Termal Monitoring
These unchangeable items list the current status of the CPU and environment temperatures,
fan speeds, and system power voltage.
・
CPUFAN0 Mode Setting
Fan conguration mode setting.
Optional: Manual Mode, Thermal Cruise Mode, Speed Cruise Mode
・
CPUFAN0 PWM Control
PWM Duty Cycle Control. This item only when “CPUFAN0 Mode Setting” setup as “Manual
Mode” is activated.
Optional: 0~255
・
CPUFAN0 TargetTemp Value
CPUFAN target temperature value. This item only when “CPUFAN0 Mode Setting” setup as
“Thermal Cruise Mode” is activated.
Optional: 0~255
・
CPUFAN0 Tolerance Value
CPUFAN Tolerance Value. This item only when “CPUFAN0 Mode Setting” setup as “Thermal
Cruise Mode” and "Speed Cruise Mode" is activated.
Optional: 0~15
・
CPUFAN0 StartUp Value
CPUFAN StartUp Value. This item only when “CPUFAN0 Mode Setting” setup as “Thermal
Cruise Mode” is activated.
Optional: 0~255
・
CPUFAN0 Stop Value
CPUFAN Stop Value. This item only when “CPUFAN0 Mode Setting” setup as “Thermal Cruise
Mode” is activated.
Optional: 0~255
・
CPUFAN0 StopTime Value
CPUFAN StopTime Value. This item only when “CPUFAN0 Mode Setting” setup as “Thermal
Cruise Mode” is activated.
Optional: 0~255
・
CPUFAN0 TargetSpeed Value
CPUFAN Target Speed Value. This item only when “CPUFAN0 Mode Setting” setup as “Speed
Cruise Mode” is activated.
Optional: 0~255
BIOS SETUP UTILITY
Power
PC Health Fan configuration
mode setting
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Sys Temperature
CPU Temperature
CFAN Speed
CPUCore Voltage Detected
+3.3 V Voltage Detected
+12 V Voltage Detected
DIMM Voltage Detected
NBCore Voltage Detected
+5 V Voltage Detected
VBAT Voltage Detected
CPUFAN0 Mode Setting
CPUFAN0 PWM Control
:16
o
C/60
o
F
:49
o
C/122
o
F
:1985 RPM
:1.192 V
:3.232 V
:12.144 V
:1.871 V
:1.200 V
:5.120 V
:3.184 V
[Manual Mode ]
[250]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
To Next Page
