Desktop Board Features
13
Table 2. Intel Desktop Board DN2800MT Components (Shown in Figure 1)
Label Description
A Battery
B Back panel connectors
C System fan header
D Internal DC power connector
E Intel NM10 Express Chipset
F BIOS configuration jumper block
G SATA 3.0 Gb/s Port 1 connector
H SATA power connector
I PCI Express Half-Mini Card slot
J SATA 3.0 Gb/s Port 0 connector
K Intel Atom processor with fanless heat sink
L LVDS connector
M FPD brightness connector
N Flat Panel voltage selection header
O Backlight inverter voltage selection header
P DDR3 SO-DIMM 0 socket
Q DDR3 SO-DIMM 1 socket
R Front panel header
S Front panel audio header
T Front panel USB 2.0 header
U Front panel USB 2.0 header (with flash drive support)
V Standby power indicator LED
W Serial port header (COM1)
X Serial port header (COM2)
Y Parallel port header
Z DMIC header
AA PCI Express Full-/Half-Mini Card slot
BB Custom solutions header
CC PCI Express 1.0a x1 add-in card connector
DD S/PDIF header
EE Internal stereo speakers connector
