Technical Reference
51
Table 17. Internal Stereo Speakers Header
Pin Signal Name Description
1 Front_L− Analog front left (differential negative)
2 Front_L+ Analog front left (differential positive)
3 Front_R+ Analog front right (differential positive)
4 Front_R− Analog front right (differential negative)
Table 18. Internal S/PDIF Header
Pin Signal Name Description
1 GND Ground
2 SPDIF_OUT SPDIF signal from the codec
3 Key (no pin) Key (no pin)
4 +5V_DC 5 V power (for optical/TOSLINK module)
Table 19. Internal DMIC Header
Pin Signal Name Description
1 +3.3 V 3.3 V power (for DMIC module)
2 DMIC_DATA DMIC data signal
3 GND Ground
4 DMIC_CLK DMIC clock signal
5 Key (no pin) Key (no pin)
Table 20. Front Panel USB Dual-Port Header
Pin Signal Name Pin Signal Name
1 +5 V DC 2 +5 V DC
3 D− 4 D−
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 No Connect
Table 21. Front Panel USB Dual-Port Header (with support for Intel Z-U130
USB Solid-State Drive or compatible device)
Pin Signal Name Pin Signal Name
1 +5 V DC 2 +5 V DC
3 D− 4 D−
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 LED#
