Intel Desktop Board DN2800MT Technical Product Specification
14
Table 2. Feature Summary (continued)
Peripheral
Interfaces
• Ten USB 2.0 ports:
Four front panel ports (via two internal headers; one header supports an
Intel
®
Z-U130 USB Solid-State Drive (or compatible device))
Two ports are implemented with stacked back panel connectors (black)
Two high-current/fast-charging ports implemented through stacked back
panel connectors (yellow)
One port implemented in the PCI Express Half-Mini Card slot
One port implemented in the PCI Express Full-/Half-Mini Card slot
• Two SATA ports:
One internal SATA connector (black)
One internal SATA connector (multiplexed with mSATA port , routed to PCI
Express Full-/Half-Mini Card slot) (gray)
Expansion
Capabilities
• One PCI Express 1.0a x1 add-in card connector
• One PCI Express Half-Mini Card slot
• One PCI Express Full-/Half-Mini Card slot
BIOS
• Intel
®
BIOS resident in the Serial Peripheral Interface (SPI) Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and System Management BIOS (SMBIOS)
LAN Support
Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Intel
®
82574L Gigabit
Ethernet Controller
Legacy I/O Control Nuvoton W83627DHG I/O controller for hardware management, serial ports and
parallel port support
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• One 3-wire system fan header
• One fan sense input used to monitor fan activity
• Fan speed control
