1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DN2800MT.
Table 1 summarizes the major features of the Desktop Board.
For a detai
led description of Intel
®
Desktop Board DN2800MT, refer to the Technical
Product Specification at http://www.intel.com/Products/Desktop/Mo
therboards/db-
DN2800MT/DN2800MT-technicaldocuments.htm.
Feature Summary
Table 1. Intel Desktop Board DN2800MT Features
Form Factor
Low-profile Mini-ITX (20 millimeters [0.79 inches] x 170.18 millimeters
[6.7 inches] x 170.18 millimeters [6.7 inches])
Processor
Fanlessly-cooled, soldered-down dual-core Intel
®
Atom™ Processor
N2800 with integrated graphics and memory controller
Chipset Intel
®
NM10 Express Chipset
Memory
• Two 204-pin Double Data Rate 3 (DDR3) Small Outline Dual Inline
Memory Module (SO-DIMM) sockets
• Support for DDR3 800 MHz and DDR3 1066 MHz SO-DIMMs
Note: Higher speed SO-DIMMs operate at 1066 MHz if supported by
the memory module.
• Support for up to 4 GB of system memory on a single SO-DIMM (or
two 2 GB SO-DIMMs)
Graphics
• Integrated graphics:
― Digital displays (High Definition Multimedia Interface* (HDMI*))
― Analog displays (VGA)
― Internal flat panel displays:
LVDS
Embedded DisplayPort* eDP*
• External graphics support via a PCI Express 1.0a x1 graphics add-in
card connector
