2.4.2 I/O Pin Mappings
Current Source
(mA)
Current Sink
(mA)
Per Pin Capability 10 25
Digital Pins 3,5,9,10,12, 13 Combined 40 100
Digital Pins 0,1,2,4,6,7,8,11 and
Analog Pins A0,A1,A2,A3,A4, A5 Combined
40 100
Digital Pins 0-13 and Analog Pins A0-A5 Combined 80 200
Table 2. Galileo I/O Mappings
Arduino
IDE ID
GPIO PWM
Int Dir Muxed with Initial Setup
Source Pin Linux Linux
IO0 Cypr GPORT4_BIT6_PWM2 50 N/A - BI UART0_RXD I w/ pullup off
IO1 Cypr GPORT4_BIT7_PWM0 51 N/A - BI UART0_TXD I w/ pullup off
IO2
SoC
(Cypr)
GPIO<6>
(GPORT2_BIT0_PWM6_A3)
14
(32*)
- 0 BI - I w/ pullup off
IO3
SoC
(Cypr)
GPIO<7>
(GPORT0_BIT2_PWM3)
15
(18*)
3 1 BI (PWM) I w/ pullup off
IO4 Cypr GPORT1_BIT4_PWM6 28 - BI - I w/ pullup off
IO5 Cypr GPORT0_BIT1_PWM5 17 5 - BI (PWM) I w/ pullup off
IO6 Cypr GPORT1_BIT0_PWM6 24 6 - BI (PWM) I w/ pullup off
IO7 Cypr GPORT1_BIT3_PWM0 27 - BI - I w/ pullup off
IO8 Cypr GPORT1_BIT2_PWM2 26 - BI - I w/ pullup off
IO9 Cypr GPORT0_BIT3_PWM1 19 1 - BI (PWM) I w/ pullup off
IO10 Cypr GPORT0_BIT0_PWM7 16 7 - BI
(PWM)
SPI1_SS_B
I w/ pullup off
IO11 Cypr GPORT1_BIT1_PWM4 25 4 - BI
(PWM)
SPI1_MOSI
I w/ pullup off
IO12 Cypr GPORT3_BIT2_PWM3 38 - BI SPI1_MISO I w/ pullup off
IO13 Cypr GPORT3_BIT3_PWM1 39 - BI SPI1_SCK I w/ pullup off
IO14 Cypr GPORT4_BIT0_PWM6 44 - BI AD7298:VIN0 I w/ pullup off
IO15 Cypr GPORT4_BIT1_PWM4 45 - BI AD7298:VIN1 I w/ pullup off
IO16 Cypr GPORT4_BIT2_PWM2 46 - BI AD7298:VIN2 I w/ pullup off
IO17 Cypr GPORT4_BIT3_PWM0 47 - BI AD7298:VIN3 I w/ pullup off
IO18 Cypr GPORT4_BIT4_PWM6 48 - BI AD7298:VIN4 I w/ pullup off
IO19 Cypr GPORT4_BIT5_PWM4 49 - BI AD7298:VIN5 I w/ pullup off

Intel Galileo Specifications

General

Product family	Intel Galileo
Product series	Intel Galileo board
Processor cache	16 KB
Processor cores	1
Processor model	Intel Quark SoC X1000
64-bit computing	No
Processor socket	Quark 393pin FCPGA
Product codename	-
Processor frequency	400 MHz
Microcontroller model	Intel Quark
Processor lithography	32 nm
Processor manufacturer	Intel
Thermal Design Power (TDP)	12.5 W
Memory bandwidth supported by processor (max)	2.5 GB/s
Memory bus	32 bit
Flash memory	8 MB
Memory channels	Single-channel
Flash memory type	Norwegian
Memory clock speed	800 MHz
Internal memory type	DDR3
Number of DIMM slots	0
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum internal memory	0.256 GB
Maximum memory card size	32 GB
SRAM (Static Random Access Memory)	512 KB
EEPROM (Electrically Erasable Programmable Read-Only Memory)	8 KB
USB version	2.0
Ethernet LAN	Yes
USB ports quantity	3
Ethernet interface type	Fast Ethernet
ARK ID	78919
Status	Discontinued
Launch date	Q4'13
Package size	15 x 15 mm
FSBs supported	NA
Processor included	Intel® Quark™ SoC X1000 (16K Cache, 400 MHz)
Supported memory types	DDR3-SDRAM
Power over Ethernet (PoE) voltage	12 V
Export Control Classification Number (ECCN)	4A994
PCI Support	PCI Express
PCI Express interface data lanes	x1
Form factor	Arduino
Market segment	Desktop
DC input voltage	5 V
Intel Small Business Advantage (SBA) version	0.00
Last change	63903513
Processor ID	79084
Product type	11
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
