Intel Galileo User Manual

Intel
®
Galileo Board—Details and Specifications
Intel
®
Galileo
Board User Guide March 2014
12 Order Number: 330237-001US
2.5 Jumpers
This section describes the jumpers on Galileo that are used to vary the configuration of
the board.
Table 3. Galileo I/O Function Multiplexing
Mux Selector
Cypress GPIO Pin
Linux
GPIO ID
Dir Initial Setup
01
UART0_RXD IO0 GPORT3_BIT4_PWM7 40 O unknown
UART0_TXD IO1 GPORT3_BIT5_PWM5 41 O unknown
SPI1_SS_B IO10 GPORT3_BIT6_PWM3 42 O unknown
SPI1_MOSI IO11 GPORT3_BIT7_PWM1 43 O unknown
SPI1_MISO IO12 GPORT5_BIT2_PWM3 54 O unknown
SPI1_SCK IO13 GPORT5_BIT3_PWM1 55 O unknown
AD7298:VIN0 IO14 GPORT3_BIT1_PWM5 37 O 0
AD7298:VIN1 IO15 GPORT3_BIT0_PWM7 36 O 0
AD7298:VIN2 IO16 GPORT0_BIT7_PWM1 23 O 0
AD7298:VIN3 IO17 GPORT0_BIT6_PWM3 22 O 0
AD7298:VIN4 IO18 GPORT0_BIT5_PWM5 21 O 0
AD7298:VIN5 IO19 GPORT0_BIT4_PWM7 20 O 0
IO2 via SoC GPIO<6>
IO2 via Cypress
GPORT2_BIT0_PWM6
GPORT1_BIT7_PWM0 31 O unknown
IO3 via SoC GPIO<7>
IO3 via Cypress
GPORT0_BIT2_PWM3
GPORT1_BIT6_PWM2 30 O unknown
I2C
(AD7298:VIN4 or IO18) and
(AD7298:VIN5 or IO19)
GPORT1_BIT5_PWM4 29 O 1

Intel Galileo Specifications

General

Product family	Intel Galileo
Product series	Intel Galileo board
Processor cache	16 KB
Processor cores	1
Processor model	Intel Quark SoC X1000
64-bit computing	No
Processor socket	Quark 393pin FCPGA
Product codename	-
Processor frequency	400 MHz
Microcontroller model	Intel Quark
Processor lithography	32 nm
Processor manufacturer	Intel
Thermal Design Power (TDP)	12.5 W
Memory bandwidth supported by processor (max)	2.5 GB/s
Memory bus	32 bit
Flash memory	8 MB
Memory channels	Single-channel
Flash memory type	Norwegian
Memory clock speed	800 MHz
Internal memory type	DDR3
Number of DIMM slots	0
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum internal memory	0.256 GB
Maximum memory card size	32 GB
SRAM (Static Random Access Memory)	512 KB
EEPROM (Electrically Erasable Programmable Read-Only Memory)	8 KB
USB version	2.0
Ethernet LAN	Yes
USB ports quantity	3
Ethernet interface type	Fast Ethernet
ARK ID	78919
Status	Discontinued
Launch date	Q4'13
Package size	15 x 15 mm
FSBs supported	NA
Processor included	Intel® Quark™ SoC X1000 (16K Cache, 400 MHz)
Supported memory types	DDR3-SDRAM
Power over Ethernet (PoE) voltage	12 V
Export Control Classification Number (ECCN)	4A994
PCI Support	PCI Express
PCI Express interface data lanes	x1
Form factor	Arduino
Market segment	Desktop
DC input voltage	5 V
Intel Small Business Advantage (SBA) version	0.00
Last change	63903513
Processor ID	79084
Product type	11
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
