Intel Galileo User Manual

Intel
®
Galileo
March 2014 Board User Guide
Order Number: 330237-001US 7
Overview—Intel
®
Galileo Board
10
Intel
®
Quark SoC
X1000
400 MHz 32-bit Intel
®
Pentium instruction set architecture
(ISA)-compatible processor
• 16 KByte L1 cache
• 512 KBytes of on-die embedded SRAM
• Simple to program: Single thread, single core, constant speed
• ACPI compatible CPU sleep states supported
• An integrated Real Time Clock (RTC), with an optional 3V "coin cell"
battery for operation between turn on cycles.
11 ICSP
6-pin in-circuit serial programming (ICSP) header, located appropriately
to plug into existing shields. These pins support SPI communication
using the SPI library.
12 256 MB DDR3 RAM 256 MByte DRAM, enabled by the firmware by default.
13 Arduino Interface
Complies with Arduino Uno Revision 3 pinout. See Section 2.4 for
details.
14 JTAG Debug Port 10-pin standard JTAG header for debugging
15 GPIO Expander GPIO pulse width modulation provided by a single I
2
C I/O expander
16 Micro SD slot (Optional) Supports micro SD card up to 32 GBytes
17 5V Power
The board is powered via an AC-to-DC adapter, connected by plugging a
2.1 mm center-positive plug into the board's power jack. The
recommended output rating of the power adapter is 5V at up to 3A.
18 Voltage Regulator
Generates 3.3 volt supply.
Maximum current draw to the shield is 800 mA.
19 Eth PHY Ethernet Physical layer transceiver
On back of board, see Figure 1.
Full PCI Express* mini-card slot, with PCIe* 2.0 compliant features:
• Works with half mini-PCIe* cards with optional converter plate
• Provides USB 2.0 Host Port at mini-PCIe* connector
Table 1. Description of Key Components (Sheet 2 of 2)
Number Component Description

Intel Galileo Specifications

General

Product family	Intel Galileo
Product series	Intel Galileo board
Processor cache	16 KB
Processor cores	1
Processor model	Intel Quark SoC X1000
64-bit computing	No
Processor socket	Quark 393pin FCPGA
Product codename	-
Processor frequency	400 MHz
Microcontroller model	Intel Quark
Processor lithography	32 nm
Processor manufacturer	Intel
Thermal Design Power (TDP)	12.5 W
Memory bandwidth supported by processor (max)	2.5 GB/s
Memory bus	32 bit
Flash memory	8 MB
Memory channels	Single-channel
Flash memory type	Norwegian
Memory clock speed	800 MHz
Internal memory type	DDR3
Number of DIMM slots	0
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum internal memory	0.256 GB
Maximum memory card size	32 GB
SRAM (Static Random Access Memory)	512 KB
EEPROM (Electrically Erasable Programmable Read-Only Memory)	8 KB
USB version	2.0
Ethernet LAN	Yes
USB ports quantity	3
Ethernet interface type	Fast Ethernet
ARK ID	78919
Status	Discontinued
Launch date	Q4'13
Package size	15 x 15 mm
FSBs supported	NA
Processor included	Intel® Quark™ SoC X1000 (16K Cache, 400 MHz)
Supported memory types	DDR3-SDRAM
Power over Ethernet (PoE) voltage	12 V
Export Control Classification Number (ECCN)	4A994
PCI Support	PCI Express
PCI Express interface data lanes	x1
Form factor	Arduino
Market segment	Desktop
DC input voltage	5 V
Intel Small Business Advantage (SBA) version	0.00
Last change	63903513
Processor ID	79084
Product type	11
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
