Intel Itanium 2 Processor - Input Signals

106 Datasheet
Signals Reference
SBSY_C1# Low BCLKp Data
SBSY_C2# Low BCLKp Data
TDO High TCK TAP
THRMTRIP# Low Asynchronous Error
THRMALERT# Low Asynchronous Error
Table A-13. Input Signals
Name Active Level Clock Signal Group Qualified
BPRI# Low BCLKp Arbitration Always
BR1# Low BCLKp Arbitration Always
BR2# Low BCLKp Arbitration Always
BR3# Low BCLKp Arbitration Always
BCLKp High — Control Always
BCLKn High — Control Always
D/C# Low BCLKp System Bus Request Phase (Mem Rd)
DEFER# Low BCLKp Snoop Snoop Phase
DHIT# Low BCLKp System Bus IDS#+1
GSEQ# Low BCLKp Snoop Snoop Phase
ID[9:0]# Low BCLKp Defer IDS#, IDS#+1
IDS# Low BCLKp Defer Always
INIT# Low Asynch Exec Control Always
1
NOTES:
1. Synchronous assertion with asserted RS[2:0]# guarantees synchronization.
INT (LINT0) High Asynch Exec Control
IP[1:0]# Low BCLKp System Bus IDS#+1
NMI (LINT1) High Asynch Exec Control
RESET# Low BCLKp Control Always
RS[2:0]# Low BCLKp Response Always
RSP# Low BCLKp Response Always
PMI# Low Asynch Exec Control
PWRGOOD High Asynch Control —
TCK High — Diagnostic Always
TDI High TCK Diagnostic Always
TMS High TCK Diagnostic Always
TRST# Low Asynch Diagnostic Always
TRDY# Low BCLKp Response Response Phase
Table A-12. Output Signals (Sheet 2 of 2)
Name Active Level Clock Signal Group
