Intel Itanium 2 Processor - Itanium 2 Processor Package Power Tab; Itanium

Datasheet 71
Mechanical Specifications
Figure 4-3. Itanium
®
2 Processor Package Power Tab
All dimensions are measured in mm. Not to scale.
001159a
Top View
Bottom View
46.96
42.21
46.00
2x 9.10 2x 12.91
4x R1.00
C
L
2.98
12x 2.92
2x 25.85
C
L
12x 38.76
90.00
45.0042.46
2x R1.20
46.74 48.26
24.13
10x 1.15
12x 0.86
2x 16.10
2.48
46.96
C
L
