Intel Itanium 2 Processor - Pin;Signal Information Sorted by Pin Name

38 Datasheet
Pinout Specifications
Table 3-1 provides the Itanium 2 processor pin list in alphabetical order.
Table 3-2 provides the Itanium 2 processor pin list by pin location.
Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 1 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
3.3V B02 IN SMBus supply voltage
A003# AA03#/EXF0# V06 IN/OUT
A004# AA04#/EXF1# V02 IN/OUT
A005# AA05#/EXF2# U03 IN/OUT
A006# AA06#/EXF3# W03 IN/OUT
A007# AA07#/EXF4# Y02 IN/OUT
A008# AA08#/BE0# Y06 IN/OUT
A009# AA09#/BE1# U07 IN/OUT
A010# AA10#/BE2# V04 IN/OUT
A011# AA11#/BE3# AA05 IN/OUT
A012# AA12#/BE4# W05 IN/OUT
A013# AA13#/BE5# Y04 IN/OUT
A014# AA14#/BE6# W07 IN/OUT
A015# AA15#/BE7# V08 IN/OUT
A016# AA16#/DID0# U13 IN/OUT
A017# AA17#/DID1# Y08 IN/OUT
A018# AA18#/DID2# U09 IN/OUT
A019# AA19#/DID3# V12 IN/OUT
A020# AA20#/DID4# V10 IN/OUT
A021# AA21#/DID5# W09 IN/OUT
A022# AA22#/DID6# W13 IN/OUT
A023# AA23#/DID7# AA11 IN/OUT
A024# AA24#/DID8# Y10 IN/OUT
A025# AA25#/DID9# Y12 IN/OUT
A026# AA26#/AB26# W11 IN/OUT
A027# AA27#/xTPRValue0# U19 IN/OUT
A028# AA28#/xTPRValue1# U15 IN/OUT
A029# AA29#/xTPRValue2# V18 IN/OUT
A030# AA30#/xTPRValue3# W19 IN/OUT
A031# AA31#/xTPRDisable# V14 IN/OUT
A032# AA32#/ATTR0# W17 IN/OUT
A033# AA33#/ATTR1# AA17 IN/OUT
A034# AA34#/ATTR2# Y14 IN/OUT
A035# AA35#/ATTR3# Y18 IN/OUT
A036# AA36#/AB36# Y16 IN/OUT
A037# AA37#/AB37# W15 IN/OUT
A038# AA38#/AB38# V16 IN/OUT
A039# AA39#/AB39# Y20 IN/OUT
