Datasheet 39
Pinout Specifications
A040# AA40#/AB40# V24 IN/OUT
A041# AA41#/AB41# W25 IN/OUT
A042# AA42#/AB42# U23 IN/OUT
A043# AA43#/AB43# Y24 IN/OUT
A044# AA44#/AB44# W21 IN/OUT
A045# AA45#/AB45# V20 IN/OUT
A046# AA46#/AB46# W23 IN/OUT
A047# AA47#/AB47# V22 IN/OUT
A048# AA48#/AB48# U21 IN/OUT
A049# AA49#/AB49# Y22 IN/OUT
A20M# A20M# AH23 IN
ADS# ADS# AB20 IN/OUT
AP0# AP0# AA25 IN/OUT
AP1# AP1# AA23 IN/OUT
BCLKn BCLKN AH13 IN
BCLKp BCLK AG13 IN
BERR# BERR# AB22 IN/OUT
BINIT# BINIT# AA15 IN/OUT
BNR# BNR# U17 IN/OUT
BPM0# BPM0# AD22 IN/OUT
BPM1# BPM1# AC25 IN/OUT
BPM2# BPM2# AE23 IN/OUT
BPM3# BPM3# AC23 IN/OUT
BPM4# BPM4# AD24 IN/OUT
BPM5# BPM5# AB24 IN/OUT
BPRI# BPRI# AE19 IN
BR0# BREQ0# AF16 IN/OUT
BR1# BREQ1# AD16 IN
BR2# BREQ2# AB18 IN
BR3# BREQ3# AF18 IN
CPUPRES# CPUPRES# AG15 OUT Power pod signal
D000# D00# C07 IN/OUT
D001# D01# E03 IN/OUT
D002# D02# C05 IN/OUT
D003# D03# D04 IN/OUT
D004# D04# D02 IN/OUT
D005# D05# D06 IN/OUT
D006# D06# F06 IN/OUT
D007# D07# F02 IN/OUT
D008# D08# G05 IN/OUT
D009# D09# H06 IN/OUT
Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 2 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
To Next Page
