Pinout Specifications
D051# D51# M12 IN/OUT
D052# D52# L13 IN/OUT
D053# D53# L09 IN/OUT
D054# D54# P08 IN/OUT
D055# D55# N13 IN/OUT
D056# D56# L11 IN/OUT
D057# D57# P12 IN/OUT
D058# D58# N09 IN/OUT
D059# D59# R13 IN/OUT
D060# D60# R11 IN/OUT
D061# D61# P10 IN/OUT
D062# D62# T12 IN/OUT
D063# D63# R09 IN/OUT
D064# D64# D18 IN/OUT
D065# D65# D14 IN/OUT
D066# D66# D16 IN/OUT
D067# D67# E15 IN/OUT
D068# D68# F14 IN/OUT
D069# D69# F18 IN/OUT
D070# D70# C19 IN/OUT
D071# D71# G15 IN/OUT
D072# D72# G17 IN/OUT
D073# D73# C17 IN/OUT
D074# D74# E19 IN/OUT
D075# D75# H14 IN/OUT
D076# D76# H16 IN/OUT
D077# D77# H18 IN/OUT
D078# D78# J15 IN/OUT
D079# D79# G19 IN/OUT
D080# D80# K18 IN/OUT
D081# D81# L15 IN/OUT
D082# D82# L19 IN/OUT
D083# D83# K16 IN/OUT
D084# D84# M14 IN/OUT
D085# D85# N19 IN/OUT
D086# D86# M18 IN/OUT
D087# D87# P14 IN/OUT
D088# D88# L17 IN/OUT
D089# D89# R17 IN/OUT
D090# D90# R19 IN/OUT
D091# D91# N15 IN/OUT
Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 4 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
