64 Datasheet
Pinout Specifications
A035# AA35#/ATTR3# Y18 IN/OUT
GND GND Y19 IN
A039# AA39#/AB39# Y20 IN/OUT
GND GND Y21 IN
A049# AA49#/AB49# Y22 IN/OUT
GND GND Y23 IN
A043# AA43#/AB43# Y24 IN/OUT
GND GND Y25 IN
GND GND AA02 IN
ID3# IDA3#/IDB3# AA03 IN
A011# AA11#/BE3# AA05 IN/OUT
DRDY0# DRDY_C1# AA07 OUT
DBSY0# DBSY_C1# AA09 OUT
A023# AA23#/DID7# AA11 IN/OUT
SBSY0# SBSY_C1# AA13 OUT
BINIT# BINIT# AA15 IN/OUT
A033# AA33#/ATTR1# AA17 IN/OUT
DBSY1# DBSY_C2# AA19 OUT
GND GND AA20 IN
DRDY1# DRDY_C2# AA21 OUT
AP1# AP1# AA23 IN/OUT
GND GND AA24 IN
AP0# AP0# AA25 IN/OUT
GND GND AB01 IN
ID1# IDA1#/IP1# AB02 IN
GND GND AB03 IN
ID5# IDA5#/IDB5# AB04 IN
GND GND AB05 IN
ID9# IDA9#/IDB9# AB06 IN
GND GND AB07 IN
RS2# RS2# AB08 IN
GND GND AB09 IN
HIT# HIT# AB10 IN/OUT
GND GND AB11 IN
HITM# HITM# AB12 IN/OUT
GND GND AB13 IN
DEFER# DEFER# AB14 IN
GND GND AB15 IN
N/C AB16
GND GND AB17 IN
BR2# BREQ2# AB18 IN
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 12 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
