Intel Itanium 2 Processor - Page 67

Datasheet 67
Pinout Specifications
GND GND AG02 IN
TUNER[2] AG03
GND GND AG04 IN
N/C AG05
GND GND AG06 IN
TDI TDI AG07 IN JTAG
GND GND AG08 IN
TCK TCK AG09 IN JTAG
GND GND AG10 IN
N/C AG11
GND GND AG12 IN
BCLKp CLK AG13 IN
GND GND AG14 IN
CPUPRES# CPUPRES# AG15 OUT Power pod signal
GND GND AG16 IN
N/C AG17
GND GND AG18 IN
N/C AG19
GND GND AG20 IN
N/C AG21
GND GND AG22 IN
IGNNE# IGNNE# AG23 IN
GND GND AG24 IN
THRMTRIP# THRMTRIP# AG25 OUT Thermal trip
GND GND AH01 IN
TUNER[1] AH03
N/C AH05
TDO TDO AH07 OUT JTAG
TMS TMS AH09 IN JTAG
N/C AH11
BCLKn BCLKN AH13 IN
PWRGOOD PWRGOOD AH15 IN
N/C AH17
N/C AH19
N/C AH21
A20M# A20M# AH23 IN
FERR# FERR# AH25 OUT
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 15 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
