Intel LV19C Series - External Locator - Rear View

Introduction
External Locator - Rear View 1 - 7
1.Introduction
External Locator - Rear View
Figure 1 - 3
Rear View
1. Camera Angle
Switch
2. USB Port Cover
3. Module Cover
4. Rear Component
Cover
5. 3 * USB 2.0
Ports
6. 1 External SATA
Port
7. DC-In Jack
8. S-Video-In Jack
9. Audio-In Jacks
10. Composite
Video-In Jack
11. CATV-In Jacks
12. RJ-11 Phone
Jack
13. RJ-45 LAN Jack
14. Stand
15. Vent/Fan Intake/
Outlet
16. Hard Disk
Covers
17. Cable Holders
(To Secure
Audio/Video/
USB Cables etc.)
