Intel LV19C Series - Mainboard Overview - Top (Cable Connectors & Switches)

Introduction
1 - 10 Mainboard Overview - Top (Cable Connectors & Switches)
1.Introduction
Mainboard Overview - Top (Cable Connectors & Switches)
1
2
3
4
6
8
9
10
11
13
5
9
12
7
Figure 1 - 6
Mainboard Top
Cable Connectors &
Switches
1. Power
2. CCD Connector
3. VGA Fan
4. Bluetooth
5. Card Reader
6. Microphone
7. Woofer
8. Modem Module
9. SATA HDD
10. SATA Power
11. CPU Fan
12. Inverter
13. LED
