2-5-4 Installing the CrossFire Card Bridge
The following illustrations show you how to install the CrossFire Bridge
Card.
In order to activate the CrossFire technology, you have to install the optional Bridge
for your CrossFire Tech. Supported VGA Cards before you activating the advance
multi-GPUs functions.
CrissFire Bridge Installation Reference
1. Install your CrossFire Tech Supported VGA
Cards in the PCI-E x16 slots.
2. Prepare with the CF Bridges with your
crossFire Tech Supported VGA Cards.
3. Be careful with the position for the pin you
would like to set up.
4. Keep straight to force the CF Bridges
plug into both sides of CrossFire Tech
Supported VGA Cards.
Notice!
The motherboard and graphics card illustrations are for reference use only;
We suggest that you install graphics cards in PE2 and PE5 slot for better
CrossFire performance;
