Technical Reference
52
Table 20. Wake on Ring Connector
Pin Signal Name
1 Ground
2 RINGA#
Table 21. Fan 3 Connector
Pin Signal Name
1 Ground
2 +12 V
3 Ground
Table 22. Wake on LAN Technology
Connector
Pin Signal Name
1 +5 VSB
2 Ground
3 WOL
Table 23. Chassis Intrusion Connector
Pin Signal Name
1 Ground
2 CHS_SEC
Table 24. Legacy CD-ROM Audio Connector
(Optional)
Pin Signal Name
1 Ground
2 CD_IN-Left
3 Ground
4 CD_IN-Right
Table 25. Optional CD-ROM Audio
Connector (black)
Pin Signal Name
1 CD_IN-Left
2 Ground
3 Ground
4 CD_IN-Right
