Intelbras AMT 2018 E - Page 31

31
Quiet Zone
KEY ADDRESS Key
Key 1 2 3 4 5 6 7 8
Key Result
Enable
Disable
Enter
7 Enter Zones 1 to 8 1 2 3 4 5 6 7 8
Enter
Note:
Zone = 01
to 48
8 Enter Zones 9 to 16 9 10 11 12 13 14 15 16
9 Enter Zones 17 to 24 17 18 19 20 21 22 23 24
10 Enter Zones 25 to 32 25 26 27 28 29 30 31 32
11 Enter Zones 33 to 40 33 34 35 36 37 38 39 40
12 Enter Zones 41 to 48 41 42 43 44 45 46 47 48
Normally Open Contact (NO) Zone
KEY ADDRESS Key
Key 1 2 3 4 5 6 7 8
Key Result
Enable
Disable
Enter
08 Enter Zones 1 to 8 1 2 3 4 5 6 7 8
Enter
Note:
Zone = 01
to 24
09 Enter Zones 9 to 16 9 10 11 12 13 14 15 16
10 Enter Zones 17 to 24 17 18 19 20 21 22 23 24
Zone Partition
Partition A Zone Selection
KEY ADDRESS Key
Key 1 2 3 4 5 6 7 8
Key Result
Enable
Disable
Enter
01 Enter Zones 1 to 8 1 2 3 4 5 6 7 8
Enter
Note:
Zone = 01
to 48
11 Enter Zones 9 to 16 9 10 11 12 13 14 15 16
12 Enter Zones 17 to 24 17 18 19 20 21 22 23 24
13 Enter Zones 25 to 32 25 26 27 28 29 30 31 32
14 Enter Zones 33 to 40 33 34 35 36 37 38 39 40
15 Enter Zones 41 to 48 41 42 43 44 45 46 47 48
Partition B Zone Selection
KEY ADDRESS Key
Key 1 2 3 4 5 6 7 8
Key Result
Enable
Disable
Enter
01 Enter Zones 1 to 8 1 2 3 4 5 6 7 8
Enter
Note:
Zone = 01
to 48
11 Enter Zones 9 to 16 9 10 11 12 13 14 15 16
12 Enter Zones 17 to 24 17 18 19 20 21 22 23 24
13 Enter Zones 25 to 32 25 26 27 28 29 30 31 32
14 Enter Zones 33 to 40 33 34 35 36 37 38 39 40
15 Enter Zones 41 to 48 41 42 43 44 45 46 47 48
