Intelbras AMT 2018 E - Connection Via Cloud

19
(7) Parallel duplication with wiring short-circuit detection
The sensors are connected in parallel at the zone input, as if they were two indepen-
dent inputs and the resistor is connected in series with the sensor.
Alarm center
Zone 11 sensor Zone 1 sensor
Here is the table with the necessary settings for the zone modes, depending on the
above conguration that was chosen in the scenario.
Zone mode Programming
(0) Single zone without end-of-line resistor ENTER + INSTALLER PASSWORD ENTER + 54 + 0 + ENTER
(1) Single zone without end-of-line resistor and
with tamper detection
ENTER + INSTALLER PASSWORD ENTER + 54 + 1 + ENTER
(2) Single zone with end of line resistor and wiring
short circuit detection
ENTER + INSTALLER PASSWORD ENTER + 54 + 2 + ENTER
(3) Single zone with end of line resistor, tamper
and wiring short circuit detection
ENTER + INSTALLER PASSWORD ENTER + 54 + 3 + ENTER
(4) Dual zone without end-of-line resistor ENTER + INSTALLER PASSWORD ENTER + 54 + 4 + ENTER
(5) Dual zone without end-of-line resistor and
with tamper detection
ENTER + INSTALLER PASSWORD ENTER + 54 + 5 + ENTER
(6) Dual zone with end of line resistor, tamper and
wiring short circuit detection
ENTER + INSTALLER PASSWORD ENTER + 54 + 6 + ENTER
(7) Parallel duplication with wiring short-circuit
detection
ENTER + INSTALLER PASSWORD ENTER + 54 + 7 + ENTER
2. Connection via Cloud
To maintain the ease of connection between the alarm center and our app via Ether-
net/GPRS and to give more security to the customers, we created a new QR Code
label model, as shown in the image below, which has the following elds:
» MAC;
» Random master password with 4 numeric digits;
» Random remote access password with 6 numeric digits.
