Intellian i3 User Manual

6
Intellian Satellite TV Antenna Systems
Basic System Conguration of Intellian
For your satellite TV system to function properly, the system will have to
be connected with all of the provided components as shown on the right
(Refer to the next chapter ‘Installation’ in this manual for more detailed
connection instructions). Separate purchase of a satellite receiver and a
TV is required.
Note: i3L can only be connected to one receiver.
Note 2: Dish and Bell TV users please refer to the Intellian Dish MIM
Installation and User Manual.
Figure 01 : Basic Conguration with 2 Receivers
ANT RF1
FUSE
FG - +
+ -
TV
(Not Supplied)
Antenna Control Unit
DC Power on Vessel
( 9~30 V DC )
NMEA GPS
PC( Not Supplied)
Satellite Receiver #2
(Not Supplied)
RF1
RF2
NMEA
RECEIVER
DC 9~30V PC INTERFACE
TV
(Not Supplied)
Satellite Receiver #1
(Not Supplied)
